Stripe Payment Gateway

This guide walks you through connecting Stripe to Open Saasframe, running your first test payment, and preparing for production with webhooks.

Optional env preconfiguration​

If your deployment already knows the Stripe credentials, you can preconfigure the Stripe integration automatically instead of filling the credentials form manually after every fresh install.

Use these env vars:

SF_INTEGRATION_STRIPE_PUBLISHABLE_KEY=pk_test_...
SF_INTEGRATION_STRIPE_SECRET_KEY=sk_test_...
SF_INTEGRATION_STRIPE_WEBHOOK_SECRET=whsec_...
SF_INTEGRATION_STRIPE_API_VERSION=2025-02-24.acacia
SF_INTEGRATION_STRIPE_ENABLED=true
SF_INTEGRATION_STRIPE_FORCE_PRECONFIGURE=false

Notes:

  • the three key values are required for preconfiguration
  • if SF_INTEGRATION_STRIPE_API_VERSION is omitted, Open Saasframe pins Stripe's default supported version
  • legacy aliases SAASFRAME_STRIPE_* and STRIPE_* are still accepted

To rerun the preset for an existing tenant:

yarn saasframe gateway_stripe configure-from-env --tenant <tenantId> --org <organizationId>

Prerequisites​

  • A Stripe account (test mode is fine for getting started).
  • Access to the Stripe Dashboard at dashboard.stripe.com.
  • The integrations.credentials.manage and payment_gateways.manage features enabled for your role.

Step 1 — Enter Stripe credentials​

  1. Navigate to External Systems → Integrations and click Configure on the Stripe card.
  2. Open the Credentials tab.
  3. Fill in three fields from your Stripe Dashboard → Developers → API keys:

Stripe credentials

FieldWhere to find itExample prefix
Publishable KeyAPI keys page — copy the publishable key for the mode (test or live) you want to usepk_test_... or pk_live_...
Secret KeyAPI keys page — reveal or rotate the secret key for the same modesk_test_... or sk_live_...
Webhook Signing SecretWebhooks page — the endpoint signing secret (see Step 4)whsec_...
  1. Click Save Credentials.
caution

Use keys from the same mode — do not mix test publishable keys with live secret keys. Stripe will reject cross-mode requests.

Step 2 — Verify health​

Switch to the Health tab and click Run Check.

Health check — Healthy

A Healthy result confirms Open Saasframe can reach the Stripe API with your credentials. The details panel shows your Stripe account ID, country, business type, and whether charges and payouts are enabled.

If the check fails, double-check the secret key and ensure it matches the mode of the publishable key.

Step 3 — Test with the Payment Gateway Demo​

Open Saasframe ships with a built-in demo page for testing the full payment lifecycle without writing code. Navigate to the Payment Gateway Demo page (available in the example module).

Authorize a payment​

Click Pay with Stripe. The demo creates a payment session through the hub, then uses Stripe.js to confirm the card payment with the test card 4242 4242 4242 4242.

Payment authorized

On success you will see:

  • A Success banner with "Payment authorized successfully."
  • Transaction Details showing the provider, transaction ID, Stripe session (Payment Intent) ID, and the internal payment ID.
  • Action buttons: Capture, Refund, Cancel, and Refresh Status.

Capture, refund, and cancel​

From the Transaction Details card:

  • Capture — settles the authorized funds. After capture the status moves to captured.
  • Refund — returns funds to the customer. After refund the status moves to refunded.

Refund successful

  • Cancel — voids the authorization before capture.
  • Refresh Status — polls Stripe for the latest Payment Intent status and updates the local transaction.

Each action calls the corresponding Payment Gateway API endpoint under the hood.

Verify on Stripe Dashboard​

After running the demo, open Stripe Dashboard → Payments. You should see the matching transaction with the same amount and status:

Stripe transactions

The description field references the Open Saasframe origin, making it easy to cross-reference.

Step 4 — Set up webhooks​

Webhooks allow Stripe to push status updates (captures, refunds, disputes) to Open Saasframe in real time, instead of relying on polling. This is strongly recommended for production.

Configure the endpoint in Stripe​

  1. Go to Stripe Dashboard → Developers → Webhooks.
  2. Click Add endpoint.
  3. Set the endpoint URL to:
https://YOUR_APP_URL/api/payment_gateways/webhook/stripe
  1. Subscribe to these events at minimum:
payment_intent.succeeded
payment_intent.payment_failed
payment_intent.canceled
payment_intent.requires_action
charge.refunded
charge.refund.updated
charge.dispute.created
charge.dispute.closed
  1. After creating the endpoint, reveal the Signing secret (starts with whsec_).
  2. Paste it into the Webhook Signing Secret field in Open Saasframe's Stripe credentials (see Step 1) and save.

Local development with ngrok​

Stripe cannot reach localhost directly. Use a tunnel:

ngrok http 3000

Then set the webhook endpoint URL in Stripe to:

https://YOUR-NGROK-SUBDOMAIN.ngrok-free.app/api/payment_gateways/webhook/stripe

Remember to update the signing secret in Open Saasframe whenever you recreate the Stripe webhook endpoint.

Step 5 — Monitor via integration logs​

After running payments, check the Logs tab on the Stripe integration page to see a full audit trail:

Integration logs

Each log entry records the operation (session created, status updated, payment captured, payment refunded), the entity type and ID, and a structured payload you can copy for debugging.

Programmatic usage​

For building custom checkout flows, headless storefronts, or server-to-server integrations, see the Payment Gateways REST API reference. It covers:

  • Creating payment sessions (POST /payment_gateways/sessions)
  • Stripe.js integration with clientSecret and publishableKey
  • Capture, refund, and cancel operations
  • Status polling and webhook processing
  • End-to-end TypeScript code examples
