Widget Injection System

The Widget Injection System provides a centralized mechanism for injecting custom widgets into admin pages, similar to dashboard widgets but generalized for any location in the admin UI.

Overview

The widget injection system allows modules to:

• Define reusable widgets with standardized event handlers
• Map widgets to specific injection spots (e.g., CRUD forms, detail pages)
• Respond to lifecycle events (onLoad, onBeforeSave, onSave, onAfterSave)
• Block or augment standard behaviors (e.g., validation, side effects)
• Render multiple widgets per spot with placement hints (stacked, grouped cards, or tabs)

Architecture

Key Components

1. Injection Widgets - React components with event handlers
2. Injection Tables - Mappings of spot IDs to widget IDs
3. Injection Spots - Locations where widgets can be injected
4. Event Handlers - Lifecycle hooks for widget behavior

UMES Phase A and B

Phase A and B add two foundational capabilities:

• Phase A (Foundation): typed placement (InjectionPosition) and headless widget loading (useInjectionDataWidgets) for non-visual extension payloads such as menu items.
• Phase B (Menu Injection): menu injection widgets (InjectionMenuItemWidget) rendered in app chrome without patching core navigation.

Menu surfaces (Phase B)

Use these spot IDs in widgets/injection-table.ts:

• menu:sidebar:main
• menu:sidebar:settings
• menu:sidebar:profile
• menu:topbar:profile-dropdown
• menu:topbar:actions

You can also target scoped IDs such as menu:sidebar:settings:<sectionId>.

Positioning injected items

Use placement on each menu item:

import { InjectionPosition } from '@saasframe/shared/modules/widgets/injection-position'

placement: { position: InjectionPosition.Before, relativeTo: 'sign-out' }

Supported positions:

• First
• Last
• Before (requires relativeTo)
• After (requires relativeTo)

If relativeTo cannot be resolved, the item is appended.

i18n requirements for injected menus

Every user-facing injected menu item should include:

• labelKey: translation key
• label: localized fallback text

For grouped sidebar/profile items:

• groupLabelKey: translation key for group label
• groupLabel: optional fallback text

Example:

const widget: InjectionMenuItemWidget = {
  metadata: { id: 'example.injection.example-menus' },
  menuItems: [
    {
      id: 'example-todos-shortcut',
      labelKey: 'example.menu.todosShortcut',
      label: 'Example Todos',
      href: '/backend/todos',
      icon: 'CheckSquare',
      features: ['example.todos.view'],
      groupId: 'example.nav.group',
      groupLabelKey: 'example.nav.group',
      placement: { position: InjectionPosition.Before, relativeTo: 'sign-out' },
    },
    {
      id: 'example-quick-add-todo',
      labelKey: 'example.menu.quickAddTodo',
      label: 'Quick Add Todo',
      href: '/backend/todos/create',
      icon: 'PlusSquare',
      features: ['example.todos.manage'],
      placement: { position: InjectionPosition.Before, relativeTo: 'sign-out' },
    },
  ],
}

Separators and relative insertion

Use separator: true to render visual separators for dropdown-style hosts. Combine with placement to insert separators before/after specific built-in items.

UMES Phase C — Events & DOM Bridge

Phase C adds real-time server-to-client event delivery and richer widget lifecycle handlers.

DOM Event Bridge (SSE)

Server-side events marked with clientBroadcast: true are automatically bridged to the browser via Server-Sent Events (SSE). The flow:

1. Server emits event via event bus (e.g., example.todo.created)
2. SSE endpoint (/api/events/stream) server-filters audience and emits only matching events to each connection
3. Client useEventBridge() hook (mounted in AppShell) receives the event
4. Dispatches a om:event CustomEvent on window
5. Widget useAppEvent hooks receive and react

Audience filtering is enforced server-side using event payload fields:

• tenantId (required)
• organizationId or organizationIds
• recipientUserId or recipientUserIds
• recipientRoleId or recipientRoleIds

When any provided audience field does not match the connection (tenant, selected organization, authenticated user, role set), the event is dropped before delivery.

Enabling broadcast on events

In your module's events.ts, add clientBroadcast: true:

export const eventsConfig = createModuleEvents('example', {
  todo: {
    created: { clientBroadcast: true },
    updated: { clientBroadcast: true },
    deleted: { clientBroadcast: true },
  },
} as const)

Consuming events in widgets

import { useAppEvent } from '@saasframe/ui/backend/injection/useAppEvent'

// Wildcard — matches example.todo.created, example.todo.updated, etc.
useAppEvent('example.todo.*', (event) => {
  console.log('Todo event:', event.id, event.payload)
  refreshData()
})

// Exact match
useAppEvent('example.todo.created', (event) => {
  flash('New todo created!', 'info')
})

Extended Widget Event Handlers (Phase C)

Widgets now support additional lifecycle handlers beyond the original save/delete/load events:

Handler	Type	Description
onFieldChange	Action	Fires when a form field changes. Can return a warning message.
onBeforeNavigate	Action	Navigation guard — return { ok: false } to block.
onVisibilityChange	Action	Fires when widget visibility changes.
onAppEvent	Action	Fires when a matching SSE event arrives.
transformFormData	Transformer	Pipeline: transform data before save.
transformDisplayData	Transformer	Pipeline: transform data before display.
transformValidation	Transformer	Pipeline: transform validation errors.

Action handlers fire independently for each widget. Transformer handlers run as a pipeline — the output of widget N becomes the input of widget N+1.

Example: Action handlers

const widget: InjectionWidgetModule = {
  metadata: { id: 'example.injection.phase-c-actions', /* ... */ },
  Widget: ActionWidget,
  eventHandlers: {
    onFieldChange: async (fieldId, value) => {
      if (fieldId === 'title' && typeof value === 'string' && value.toUpperCase().includes('TEST')) {
        return {
          message: { text: 'Title contains "TEST" — is this intentional?', severity: 'warning' },
        }
      }
    },
    onBeforeNavigate: async (target) => {
      if (target.includes('/blocked')) {
        return { ok: false, message: 'Navigation blocked by widget policy' }
      }
      return { ok: true }
    },
    onVisibilityChange: async (visible, context) => {
      context.sharedState?.set('lastVisibility', visible)
    },
    onAppEvent: async (event, context) => {
      context.sharedState?.set('lastEventId', event.id)
    },
  },
}

Example: Transformer handlers

const widget: InjectionWidgetModule = {
  metadata: { id: 'example.injection.phase-c-transformers', /* ... */ },
  Widget: TransformerWidget,
  eventHandlers: {
    transformFormData: async (data, context) => {
      const trimmed = { ...data }
      for (const [key, value] of Object.entries(trimmed)) {
        if (typeof value === 'string') trimmed[key] = value.trim()
      }
      return trimmed
    },
    transformDisplayData: async (data) => {
      return {
        ...data,
        title: typeof data.title === 'string' ? data.title.toUpperCase() : data.title,
      }
    },
    transformValidation: async (errors) => {
      if (!errors.title) return errors
      return { ...errors }
    },
  },
}

Integration Test Coverage (Phase C)

Use a small test harness page that mounts the widget and calls useInjectionSpotEvents(...) to trigger each handler deterministically.

Recommended Playwright coverage:

Test ID	What to verify
TC-UMES-E03	onFieldChange updates warning state when title contains TEST.
TC-UMES-E04	transformFormData trims input (" x " → "x").
TC-UMES-E07	onBeforeNavigate blocks /blocked and allows safe targets.
TC-UMES-E08	onVisibilityChange stores latest visibility state.
TC-UMES-E09	onAppEvent runs when om:event (example.todo.created) is dispatched.
TC-UMES-E10	transformDisplayData and transformValidation mutate output as expected.

How to run:

npx playwright test --config .ai/qa/tests/playwright.config.ts apps/saasframe/src/modules/example/__integration__/TC-UMES-003.spec.ts

CrudForm Env Toggle

CrudForm emits Phase C handlers by default.

Set this variable to disable automatic emission:

NEXT_PUBLIC_SF_CRUDFORM_EXTENDED_EVENTS_ENABLED=false

When enabled (true, default), CrudForm emits:

• onFieldChange on field writes (setValue)
• onBeforeNavigate before guarded in-form navigation and CrudForm redirects
• onVisibilityChange on browser visibilitychange
• onAppEvent when om:event is received
• transformFormData before save pipeline
• transformDisplayData when initial form values are applied
• transformValidation before setting form field errors

Example Injection Widgets Toggle

The example module ships demo injection widgets (CRUD validation panel, sales todos tab, catalog SEO report, sample menu items).

These widgets are disabled by default. Enable them with:

NEXT_PUBLIC_SF_EXAMPLE_INJECTION_WIDGETS_ENABLED=true

Default:

NEXT_PUBLIC_SF_EXAMPLE_INJECTION_WIDGETS_ENABLED=false

Operation Progress Tracking

Track long-running server operations in widgets:

import { useOperationProgress } from '@saasframe/ui/backend/injection/useOperationProgress'

function ImportProgressWidget() {
  const progress = useOperationProgress('catalog.import.*')
  if (progress.status === 'idle') return null
  return <ProgressBar value={progress.progress} label={progress.currentStep} />
}

UMES Phase D — Response Enrichers

Phase D adds a federation-like data enrichment system. Modules can inject computed fields into other modules' API responses without modifying core code.

How It Works

1. Module defines enrichers in data/enrichers.ts
2. Generator discovers and registers them at bootstrap
3. CRUD factory calls enrichers after afterList hook, before HTTP response
4. Enriched fields appear under a _<moduleName> namespace
5. Response includes _meta.enrichedBy tracking which enrichers ran

Creating a Response Enricher

Create src/modules/<module>/data/enrichers.ts:

import type { ResponseEnricher } from '@saasframe/shared/lib/crud/response-enricher'

const customerTodoCount: ResponseEnricher = {
  id: 'example.customer-todo-count',
  targetEntity: 'customers.person',      // which entity to enrich
  features: ['example.view'],            // ACL gating
  priority: 10,                          // higher = runs first
  timeout: 2000,                         // max ms per enricher
  fallback: { _example: { todoCount: 0 } }, // used on timeout/error

  async enrichOne(record, context) {
    const em = context.em.fork()
    const count = await em.count(Todo, { organizationId: context.organizationId })
    return { ...record, _example: { todoCount: count } }
  },

  // MUST implement for list endpoints (prevents N+1 queries)
  async enrichMany(records, context) {
    const em = context.em.fork()
    const todos = await em.find(Todo, { organizationId: context.organizationId })
    return records.map(r => ({ ...r, _example: { todoCount: todos.length } }))
  },
}

export const enrichers: ResponseEnricher[] = [customerTodoCount]

Opting In on CRUD Routes

Add enrichers to your makeCrudRoute call:

export const { metadata, GET, POST, PUT, DELETE } = makeCrudRoute({
  // ... other config
  enrichers: { entityId: 'customers.person' },
})

API Response Shape

{
  "items": [
    {
      "id": "abc-123",
      "firstName": "John",
      "_example": { "todoCount": 5, "openTodoCount": 3 }
    }
  ],
  "_meta": {
    "enrichedBy": ["example.customer-todo-count"]
  }
}

Key Rules

• Enriched fields MUST be namespaced under _<moduleName> (e.g., _example.todoCount)
• Enrichers are additive-only — never modify or remove existing fields
• enrichMany() is mandatory for list endpoints (batch queries prevent N+1)
• EntityManager usage is read-only — no writes in enrichers
• Non-critical enrichers fail silently (use fallback); set critical: true to propagate errors
• Export paths automatically strip enricher fields (anything prefixed with _)
• Keep cacheableOnListHit at its false default unless the enriched output is record-pure — see below

List Cache Interaction (cacheableOnListHit)

When the opt-in CRUD list cache (ENABLE_CRUD_API_CACHE) is on, the factory stores the enriched list payload and partitions cache entries by the set of enrichers active for the caller (after ACL + tenant filtering). What happens on a cache hit depends on whether the active enrichers are cacheable:

• If every active enricher sets cacheableOnListHit: true, the hit serves the stored enriched fields directly without re-running enrichers — this is the fast path that makes list caching actually eliminate enrichment cost.
• Otherwise the hit re-runs all active enrichers and the cache stores only the base (pre-enrichment) payload, so non-cacheable enrichers always reflect current data.

const customerStatusBadge: ResponseEnricher = {
  id: 'example.customer-status-badge',
  targetEntity: 'customers.person',
  cacheableOnListHit: true, // pure function of the record's own cached fields → safe on a hit
  // ...
}

The shipped example.customer-todo-count enricher, by contrast, reads other modules' tables, so it keeps the false default and re-runs on every hit.

Set cacheableOnListHit: true only when the enricher's output for a record is a pure function of that record's own cached state and is invalidated together with it. Leave it false (the fail-closed default) for any enricher whose output depends on data the list cache does not invalidate on:

• cross-module / cross-entity reads (e.g. a product image fetched for a sales line),
• wall-clock-relative values (e.g. "days in stage"),
• aggregates over other tables.

Opting in on such an enricher would serve stale values from the shared cache entry on a hit.

Directory Structure

src/modules/<module>/
├── data/
│   └── enrichers.ts          # Response enrichers (auto-discovered)
├── widgets/
│   ├── injection/
│   │   └── <widget-name>/
│   │       ├── widget.ts          # Widget definition & event handlers
│   │       └── widget.client.tsx  # React component (client-side)
│   └── injection-table.ts         # Spot ID → Widget ID mappings

Built-in Injection Spots

• CRUD forms: crud-form:<entityId> (automatically derived from entityId/entityIds passed to CrudForm). Widgets can request placement.kind: 'group' to render as a side-card and column: 2 to appear in the right column. Field injection spot: crud-form:<entityId>:fields.
• Data tables: data-table:<tableId> (or pass injectionSpotId to DataTable). Header/footer child spots: :header, :footer. Deep extension spots: :columns, :row-actions, :bulk-actions, :filters, :toolbar, :search-trailing.
  • :toolbar renders inside the right-side actions row alongside Refresh / Filters / Columns / Export. Suitable for full-sized toolbar buttons.
  • :search-trailing renders inside the FilterBar, immediately to the right of the search input on the same row. Reserve it for compact triggers — AI assistants, saved-view shortcuts, focus toggles. Full-width or multi-action toolbars belong in :toolbar or :header. The slot is automatically suppressed when the host DataTable does not render a search input. Use Button variant="outline" (default size, h-9, rounded-md) with a single leading icon plus a short caption (e.g. AI) so the trigger matches the search input's h-9 row height and the toolbar's standard rounded-rectangle button radius. Resolve the spot id with DataTableInjectionSpots.searchTrailing(tableId) from @saasframe/ui/backend/injection/spotIds.
• Backend record context: backend:record:current (mounted once per backend page with { path, query } context).
• Backend layout: backend:layout:top, backend:layout:footer (top and bottom of the main backend content area).
• Backend sidebar: backend:sidebar:top, backend:sidebar:footer (desktop sidebar top/bottom areas in AppShell).

Replacement Handles

Component replacement uses stable handle IDs:

• page:<path> for backend page-level replacement (for example page:/backend/customers/people)
• data-table:<tableId> for each DataTable instance
• crud-form:<entityId> for each CrudForm instance
• section:<scope>.<sectionName> for detail sections (for example section:ui.detail.NotesSection)
• Module overrides are auto-discovered from widgets/components.ts (componentOverrides) and generated to .saasframe/generated/component-overrides.generated.ts.
• Shared detail sections expose stable handles:
  • section:ui.detail.NotesSection
  • section:ui.detail.ActivitiesSection
  • section:ui.detail.AddressesSection
  • section:ui.detail.TagsSection
  • section:ui.detail.CustomDataSection
  • section:ui.detail.DetailFieldsSection
  • section:ui.detail.AttachmentsSection
• Admin layout wrapper: admin.page:<path-handle>:before|after from PageInjectionBoundary (wraps every backend page).
• Global backend mutations: GLOBAL_MUTATION_INJECTION_SPOT_ID resolves to backend:record:current for non-CrudForm save hooks. backend-mutation:global is still mounted in AppShell as a legacy compatibility slot.

UMES Phase L — Integration Extension Widgets

Phase L adds three specialized widget types for building integration modules: a multi-step wizard, pollable status badges, and an external ID mapping display.

InjectionWizard

A multi-step wizard component for integration onboarding flows (OAuth setup, API credential entry, sync configuration).

Step definition

Each step is an InjectionWizardStep with:

• id — unique step identifier
• label — displayed in the step indicator (supports i18n keys)
• description — optional subtitle text
• fields — optional array of InjectedField definitions (text, select, etc.)
• validate — optional async function returning { ok, message?, fieldErrors? }
• customComponent — optional React component for fully custom step content

Usage

import { InjectionWizard } from '@saasframe/ui/backend/injection/InjectionWizard'
import type { InjectionWizardWidget, InjectionContext } from '@saasframe/shared/modules/widgets/injection'

const widget: InjectionWizardWidget = {
  metadata: { id: 'my_module.integration.setup-wizard', title: 'Integration Setup' },
  kind: 'wizard',
  steps: [
    {
      id: 'credentials',
      label: 'Credentials',
      fields: [
        { id: 'apiKey', label: 'API Key', type: 'text' },
        { id: 'apiSecret', label: 'API Secret', type: 'text' },
      ],
      validate: async (data) => {
        if (!data.apiKey || !data.apiSecret) {
          return { ok: false, message: 'Both fields are required.' }
        }
        return { ok: true }
      },
    },
    { id: 'scope', label: 'Scope', fields: [/* ... */] },
  ],
  onComplete: async (allData, context) => {
    // Save integration config
  },
}

<InjectionWizard widget={widget} context={context} />

The wizard renders a numbered step indicator with connecting lines, validates each step before allowing progression, and calls onComplete with accumulated data from all steps. Escape cancels the wizard.

StatusBadgeRenderer

A pollable status badge for displaying integration or service health.

Badge definition

An InjectionStatusBadgeWidget contains a badge object with:

• label — display text (supports i18n)
• statusLoader — async function returning { status, tooltip?, count? }
• pollInterval — refresh interval in seconds (default: 60)
• href — optional link target

Status values and their colors:

Status	Color
healthy	Green
warning	Yellow
error	Red
unknown	Gray

Usage

import { StatusBadgeRenderer } from '@saasframe/ui/backend/injection/StatusBadgeRenderer'
import type { InjectionStatusBadgeWidget, StatusBadgeContext } from '@saasframe/shared/modules/widgets/injection'

const widget: InjectionStatusBadgeWidget = {
  metadata: { id: 'my_module.integration.sync-status' },
  kind: 'status-badge',
  badge: {
    label: 'Sync Engine',
    pollInterval: 30,
    statusLoader: async (ctx) => {
      const res = await fetch('/api/integrations/health')
      const data = await res.json()
      return { status: data.healthy ? 'healthy' : 'error', tooltip: data.message }
    },
  },
}

<StatusBadgeRenderer widget={widget} context={context} />

ExternalIdsWidget

Displays external system ID mappings from the _integrations namespace added by the external ID mapping enricher (see Data extensibility).

Each row shows:

• Provider name — resolved via getIntegrationTitle() from the integration registry
• External ID — monospace code badge
• Sync status — color-coded dot (synced/pending/error/not_synced)
• External link — icon linking to the record in the external system (when buildExternalUrl is registered)

The widget reads data._integrations (keyed by integration ID) and renders automatically when enriched data is available. It is registered as an injection widget at integrations.injection.external-ids.

Widget source: packages/core/src/modules/integrations/widgets/injection/external-ids/widget.client.tsx

Creating an Injection Widget

1. Define the Widget

Create src/modules/<module>/widgets/injection/<widget-name>/widget.ts:

import type { InjectionWidgetModule } from '@saasframe/shared/modules/widgets/injection'
import MyWidgetClient from './widget.client'

const widget: InjectionWidgetModule<ContextType, DataType> = {
  metadata: {
    id: 'module.injection.widget-name',
    title: 'Widget Title',
    description: 'Widget description',
    features: ['module.feature'],
    priority: 100,
    enabled: true,
  },
  Widget: MyWidgetClient,
  eventHandlers: {
    onLoad: async (context) => {
      // Called when widget loads
      console.log('Widget loaded', context)
    },
    onBeforeSave: async (data, context) => {
      // Called before save action
      // Return false to prevent save, or provide a message/field errors
      if (!isValid(data)) {
        return {
          ok: false,
          message: 'Title is required before saving',
          fieldErrors: { title: 'Title is required' },
        }
      }
      return { ok: true }
    },
    onSave: async (data, context) => {
      // Called during save action
      console.log('Saving', data)
    },
    onAfterSave: async (data, context) => {
      // Called after successful save
      console.log('Saved', data)
    },
  },
}

export default widget

2. Create the Widget Component

Create src/modules/<module>/widgets/injection/<widget-name>/widget.client.tsx:

"use client"
import * as React from 'react'
import type { InjectionWidgetComponentProps } from '@saasframe/shared/modules/widgets/injection'

export default function MyWidget({ context, data, onDataChange, disabled }: InjectionWidgetComponentProps) {
  return (
    <div className="rounded border border-blue-200 bg-blue-50 p-3 text-sm">
      <div className="font-medium text-blue-900">My Widget</div>
      <div className="text-blue-700 mt-1">
        Custom content here. Context: {JSON.stringify(context)}
      </div>
      {disabled && <div className="text-xs text-gray-500 mt-1">Saving...</div>}
    </div>
  )
}

3. Register in Injection Table

Create or edit src/modules/<module>/widgets/injection-table.ts:

import type { ModuleInjectionTable } from '@saasframe/shared/modules/widgets/injection'

export const injectionTable: ModuleInjectionTable = {
  // Map injection spot IDs to widget IDs
  'crud-form:catalog.product': 'module.injection.widget-name',

  // Can also inject multiple widgets
  'crud-form:catalog.variant': [
    'module.injection.widget-name',
    'module.injection.another-widget',
  ],
}

export default injectionTable

Using Injection Spots in CRUD Forms

The CrudForm component automatically supports widget injection:

<CrudForm
  fields={fields}
  onSubmit={handleSubmit}
  injectionSpotId="crud-form:catalog.product"
  // ... other props
/>

Standard Injection Spot IDs

Use the helper functions to generate consistent spot IDs:

import { generateCrudFormInjectionSpotId, CrudFormInjectionSpots } from '@saasframe/ui/backend/injection/helpers'

// Basic form spot
const spotId = generateCrudFormInjectionSpotId('catalog.product')
// Result: 'crud-form:catalog.product'

// Specific locations
const beforeFieldsSpot = CrudFormInjectionSpots.beforeFields('catalog.product')
// Result: 'crud-form:catalog.product:before-fields'

const afterFieldsSpot = CrudFormInjectionSpots.afterFields('catalog.product')
// Result: 'crud-form:catalog.product:after-fields'

Event Handler Reference

onLoad

Called when the widget is first mounted.

Signature:

onLoad?: (context: TContext) => void | Promise<void>

Use Cases:

• Initialize widget state
• Fetch additional data
• Register listeners

onBeforeSave

Called before a save action is executed. Can prevent the save by returning false or throwing an error.

Signature:

onBeforeSave?: (data: TData, context: TContext) => boolean | { ok?: boolean; message?: string; fieldErrors?: Record<string, string> } | void | Promise<boolean | { ok?: boolean; message?: string; fieldErrors?: Record<string, string> } | void>

Use Cases:

• Validation
• Confirmation dialogs
• Data transformation
• Blocking invalid operations

Example:

onBeforeSave: async (data, context) => {
  if (!data.title || data.title.length < 10) {
    alert('Title must be at least 10 characters')
    return false  // Prevent save
  }
  return true  // Allow save
}

onSave

Called when save action is triggered (alongside the main save operation).

Signature:

onSave?: (data: TData, context: TContext) => void | Promise<void>

Use Cases:

• Side effects during save
• Logging
• Analytics

onAfterSave

Called after save completes successfully.

Signature:

onAfterSave?: (data: TData, context: TContext) => void | Promise<void>

Use Cases:

• Success notifications
• Cache invalidation
• Related data updates

Advanced Usage

Using the Injection Spot Hook

For custom components that need to trigger injection widget events:

import { useInjectionSpotEvents } from '@saasframe/ui/backend/injection/InjectionSpot'

function MyCustomForm() {
  const { triggerEvent } = useInjectionSpotEvents('crud-form:my.form')

  const handleSave = async (data) => {
    // Trigger onBeforeSave
    const canProceed = await triggerEvent('onBeforeSave', data, context)
    if (!canProceed) {
      return // Blocked by widget
    }

    // Trigger onSave
    await triggerEvent('onSave', data, context)

    // Perform save
    await saveData(data)

    // Trigger onAfterSave
    await triggerEvent('onAfterSave', data, context)
  }

  return <form onSubmit={handleSave}>...</form>
}

Global Mutation Hook for Non-CrudForm Screens

For backend pages that do not use CrudForm (for example custom detail screens), use the global mutation spot and emit the generic mutation error event.

import { useInjectionSpotEvents } from '@saasframe/ui/backend/injection/InjectionSpot'
import {
  GLOBAL_MUTATION_INJECTION_SPOT_ID,
  dispatchBackendMutationError,
} from '@saasframe/ui/backend/injection/mutationEvents'
import { withScopedApiRequestHeaders } from '@saasframe/ui/backend/utils/apiCall'

const { triggerEvent } = useInjectionSpotEvents(GLOBAL_MUTATION_INJECTION_SPOT_ID)

async function runMutation(operation: () => Promise<unknown>, payload: Record<string, unknown>, context: Record<string, unknown>) {
  const beforeSave = await triggerEvent('onBeforeSave', payload, context)
  if (!beforeSave.ok) {
    dispatchBackendMutationError({ contextId: context.formId as string, error: beforeSave.details ?? beforeSave })
    throw new Error(beforeSave.message ?? 'Save blocked by validation')
  }

  try {
    const result =
      beforeSave.requestHeaders && Object.keys(beforeSave.requestHeaders).length > 0
        ? await withScopedApiRequestHeaders(beforeSave.requestHeaders, operation)
        : await operation()
    await triggerEvent('onAfterSave', payload, context)
    return result
  } catch (error) {
    dispatchBackendMutationError({ contextId: context.formId as string, error })
    throw error
  }
}

This keeps API helpers generic while still enabling module-level behaviors such as conflict dialogs, validation, or save guards.

Directly Rendering an Injection Spot

import { InjectionSpot } from '@saasframe/ui/backend/injection/InjectionSpot'

function MyPage() {
  const context = { pageId: 'my-page', userId: currentUser.id }
  const [data, setData] = useState({})

  return (
    <div>
      <InjectionSpot
        spotId="page:my-page:header"
        context={context}
        data={data}
        onDataChange={setData}
      />
      {/* Rest of page */}
    </div>
  )
}

Examples

Here’s how injected widgets look in the admin UI:

See these modules for reference implementations:

• packages/example/src/modules/example/widgets/injection/crud-validation - Basic validation widget
• packages/core/src/modules/catalog/widgets/injection/product-seo - SEO helper widget for products

Code Generation

The widget injection system is integrated into the module code generator:

1. Widgets in src/modules/<module>/widgets/injection/**/widget.ts(x) are auto-discovered
2. Injection tables in src/modules/<module>/widgets/injection-table.ts are auto-loaded
3. Generated registry files are created in generated/injection-widgets.generated.ts
4. Run yarn generate to regenerate

Best Practices

1. Keep widgets focused - Each widget should have a single, clear purpose
2. Use descriptive IDs - Follow the pattern module.injection.widget-name
3. Handle errors gracefully - Catch errors in event handlers to avoid breaking the form
4. Document context requirements - Clearly specify what data the widget expects in context
5. Use TypeScript - Leverage type safety for context and data types
6. Test event handlers - Ensure validation logic works correctly
7. Respect disabled state - Disable UI interactions when disabled prop is true

Troubleshooting

Widget not appearing

1. Check that the widget is in the correct directory structure
2. Verify the injection table maps the spot ID correctly
3. Run yarn generate to regenerate
4. Check browser console for loading errors

Events not firing

1. Ensure the injection spot ID matches exactly
2. Check that event handlers are defined in the widget module
3. Verify the host component is using useInjectionSpotEvents or InjectionSpot
4. Check for errors in the event handler itself

TypeScript errors

1. Import types from @saasframe/shared/modules/widgets/injection
2. Use the correct generic types for context and data
3. Ensure the widget module default export matches InjectionWidgetModule
