Messages System

The Messages module provides internal, tenant-scoped messaging with inbox/sent/drafts flows, deterministic object attachment, file attachments, actionable buttons, and optional email forwarding with token-based access links.

Overview

Location: packages/core/src/modules/messages/
UI Components: packages/ui/src/backend/messages/
Package: @saasframe/core
Auto refresh: Polling every 5 seconds via useMessagesPoll
Threading: Native reply/reply-all and forward flows with actor-visibility filtering
Actionable: Message-level action buttons with command/link support
Module-extensible: Add message types and object types in module files and let generated bootstrap register them

End-user flow

1) List of messages

Messages list

2) Compose messages

Composing a message

3) Attaching objects while composing a message

Attaching object to message

4) Message details

Attaching object to message

Key Features

Inbox, sent, drafts, archived, and all folders with filters/pagination
Rich compose flow with recipients (to/cc/bcc), priority, and body format
Object attachments scoped by selected message type (/api/messages/object-types)
File attachment picker integrated with the attachments module
Message actions with confirmation and execution state tracking
Built-in confirmation message type (messages.confirmation) with status endpoint
Object attachment message type (messages.defaultWithObjects) for business object linking
Optional email delivery and token-based message view page
Multi-tenant + organization-aware isolation on all APIs
Conversation-scoped operations (archive, mark unread, delete) scoped to the current actor

Quick Start

1. Compose and Send a Message

import { apiCallOrThrow } from '@saasframe/ui/backend/utils/apiCall'

await apiCallOrThrow('/api/messages', {
  method: 'POST',
  body: JSON.stringify({
    type: 'staff.leave_request_approval',
    recipients: [{ userId: 'recipient-user-uuid', type: 'to' }],
    subject: 'Leave request needs review',
    body: 'Please review and approve or reject this leave request.',
    bodyFormat: 'text',
    priority: 'high',
    objects: [
      {
        entityModule: 'staff',
        entityType: 'leave_request',
        entityId: 'leave-request-uuid',
      },
    ],
    sendViaEmail: false,
    isDraft: false,
  }),
})

2. Save or Update Drafts

// Save draft
await apiCallOrThrow('/api/messages', {
  method: 'POST',
  body: JSON.stringify({
    type: 'default',
    recipients: [{ userId: 'recipient-user-uuid', type: 'to' }],
    subject: 'Draft message',
    body: 'Draft content',
    isDraft: true,
  }),
})

// Update existing draft
await apiCallOrThrow(`/api/messages/${draftId}`, {
  method: 'PATCH',
  body: JSON.stringify({
    subject: 'Updated draft subject',
    body: 'Updated draft body',
  }),
})

3. Add Real-Time Inbox Badge Updates

'use client'

import { MessagesIcon } from '@saasframe/ui/backend/messages'

export function HeaderMessagesButton() {
  return <MessagesIcon className="h-5 w-5" />
}

MessagesIcon uses useMessagesPoll() to poll inbox + unread count every 5 seconds.

Message Input Schema

Compose Payload Shape

{
  type?: string // default: 'default'
  recipients?: Array<{ userId: string; type?: 'to' | 'cc' | 'bcc' }>
  subject?: string
  body?: string
  visibility?: 'public' | 'internal' | null
  sourceEntityType?: string
  sourceEntityId?: string

  externalEmail?: string
  externalName?: string

  bodyFormat?: 'text' | 'markdown' // default: 'text'
  priority?: 'low' | 'normal' | 'high' | 'urgent' // default: 'normal'

  // Deterministic object attachments
  objects?: Array<{
    entityModule: string
    entityType: string
    entityId: string
    actionRequired?: boolean
    actionType?: string
    actionLabel?: string
  }>

  // File attachments (from picker)
  attachmentIds?: string[]
  attachmentRecordId?: string // temporary picker record id

  // Message-level actions
  actionData?: {
    actions: Array<{
      id: string
      label: string
      labelKey?: string
      variant?: 'default' | 'secondary' | 'destructive' | 'outline' | 'ghost'
      icon?: string
      commandId?: string
      href?: string
      isTerminal?: boolean
      confirmRequired?: boolean
      confirmMessage?: string
    }>
    primaryActionId?: string
    expiresAt?: string
  }

  sendViaEmail?: boolean
  parentMessageId?: string
  isDraft?: boolean
}

Validation Rules

For non-drafts (isDraft: false): subject and body are required.
For non-drafts with visibility: 'internal': at least one recipient is required.
For non-drafts with visibility: 'public': externalEmail is required and recipients must be empty.
Recipient user IDs must be unique.

Validation is defined in packages/core/src/modules/messages/data/validators.ts and enforces pageSize <= 100 for list/object-option routes.

API Routes

All routes live under packages/core/src/modules/messages/api/ and export openApi docs.

Route	Methods	Purpose
`/api/messages`	`GET`, `POST`	List folders and compose/send message
`/api/messages/[id]`	`GET`, `PATCH`, `DELETE`	Message detail, draft update, contextual delete
`/api/messages/[id]/reply`	`POST`	Reply/reply-all within thread
`/api/messages/[id]/forward`	`POST`	Forward message
`/api/messages/[id]/forward-preview`	`GET`	Preview forward body (thread history up to message)
`/api/messages/[id]/read`	`PUT`, `DELETE`	Mark read / unread
`/api/messages/[id]/archive`	`PUT`, `DELETE`	Archive / unarchive
`/api/messages/[id]/conversation`	`DELETE`	Delete entire conversation from actor's view
`/api/messages/[id]/actions/[actionId]`	`POST`	Execute action button
`/api/messages/[id]/confirmation`	`GET`	Read confirmation status (`confirmed`, `confirmedAt`, `confirmedByUserId`)
`/api/messages/[id]/attachments`	`GET`, `POST`, `DELETE`	List/link/unlink draft attachments
`/api/messages/unread-count`	`GET`	Inbox unread badge count
`/api/messages/types`	`GET`	Registered message types
`/api/messages/object-types`	`GET`	Allowed object types for selected message type
`/api/messages/token/[token]`	`GET`	Resolve email token to message payload

Conversation-Scoped Operations

The DELETE /api/messages/[id]/conversation endpoint removes the entire conversation from the current actor's view. It does not delete messages for other participants — the sender always retains a copy. This is the correct endpoint to use when a user wants to "delete" a conversation from their inbox.

Thread visibility in GET /api/messages/[id] is actor-filtered: only thread messages where the actor is the sender or an explicit recipient are included in the response.

UI Pages

Backend Pages

/backend/messages (packages/core/src/modules/messages/backend/page.tsx)
/backend/messages/[id] (packages/core/src/modules/messages/backend/messages/[id]/page.tsx)
/backend/messages/compose (packages/core/src/modules/messages/backend/messages/compose/page.tsx)

Public Token Page

/messages/view/[token] (packages/core/src/modules/messages/frontend/messages/view/[token]/page.tsx)

Shared UI Components

MessageComposer
MessageAttachmentPicker
MessagesIcon
useMessagesPoll

All exported from @saasframe/ui/backend/messages.

Message Types (Module Extension)

Message type definitions are declared in each module's message-types.ts and auto-registered from generated bootstrap imports (@/.saasframe/generated/message-types.generated in apps/saasframe/src/bootstrap.ts).

// packages/core/src/modules/staff/message-types.ts
import type { MessageTypeDefinition } from '@saasframe/shared/modules/messages/types'

export const messageTypes: MessageTypeDefinition[] = [
  {
    type: 'staff.leave_request_approval',
    module: 'staff',
    labelKey: 'staff.messages.leaveRequestApproval',
    icon: 'calendar-clock',
    color: 'amber',
    ui: {
      listItemComponent: 'messages.default.listItem',
      contentComponent: 'messages.default.content',
      actionsComponent: 'messages.default.actions',
    },
    allowReply: true,
    allowForward: true,
    actionsExpireAfterHours: 168,
  },
]

Built-in Types

default (reply + forward enabled)
messages.confirmation (includes default confirm action via messages.confirmations.confirm)
messages.defaultWithObjects (for messages that carry attached business objects; reply + forward enabled)

Defined in packages/core/src/modules/messages/message-types.ts.

Object Types (Deterministic Attachments)

Object type definitions are declared in each module's message-objects.ts and auto-registered from generated bootstrap imports (@/.saasframe/generated/message-objects.generated in apps/saasframe/src/bootstrap.ts).

Each module that registers object types must expose PreviewComponent and DetailComponent via a widgets/messages/ barrel export:

packages/core/src/modules/{module}/
├── message-objects.ts           # Object type definitions
└── widgets/
    └── messages/
        ├── index.ts             # Barrel: exports Preview + Detail components
        ├── MyModuleObjectPreview.tsx
        └── MyModuleObjectDetail.tsx

Defining Object Types

// packages/core/src/modules/staff/message-objects.ts
import type { MessageObjectTypeDefinition } from '@saasframe/shared/modules/messages/types'
import { StaffMessageObjectDetail } from './widgets/messages/StaffMessageObjectDetail'
import { StaffMessageObjectPreview } from './widgets/messages/StaffMessageObjectPreview'

export const messageObjectTypes: MessageObjectTypeDefinition[] = [
  {
    module: 'staff',
    entityType: 'team',
    messageTypes: ['default', 'messages.defaultWithObjects'],
    entityId: 'staff:staff_team',
    optionLabelField: 'name',
    optionSubtitleField: 'description',
    labelKey: 'staff.teams.page.title',
    icon: 'users',
    PreviewComponent: StaffMessageObjectPreview,
    DetailComponent: StaffMessageObjectDetail,
    actions: [],
    loadPreview: async (entityId, ctx) => {
      if (typeof window !== 'undefined') {
        return { title: 'Team', subtitle: entityId }
      }
      const { loadTeamPreview } = await import('./lib/messageObjectPreviews')
      return loadTeamPreview(entityId, ctx)
    },
  },
  {
    module: 'staff',
    entityType: 'leave_request',
    messageTypes: ['default', 'messages.defaultWithObjects', 'staff.leave_request_approval', 'staff.leave_request_status'],
    entityId: 'staff:staff_leave_request',
    optionLabelField: 'id',
    optionSubtitleField: 'status',
    labelKey: 'staff.leaveRequests.page.title',
    icon: 'calendar-clock',
    PreviewComponent: LeaveRequestPreview,
    DetailComponent: LeaveRequestDetail,
    actions: [
      {
        id: 'approve',
        labelKey: 'staff.notifications.leaveRequest.actions.approve',
        variant: 'default',
        commandId: 'staff.leave-requests.accept',
        icon: 'check',
      },
      {
        id: 'reject',
        labelKey: 'staff.notifications.leaveRequest.actions.reject',
        variant: 'destructive',
        commandId: 'staff.leave-requests.reject',
        icon: 'x',
      },
      {
        id: 'view',
        labelKey: 'common.view',
        variant: 'outline',
        href: '/backend/staff/leave-requests/{entityId}',
        icon: 'external-link',
        isTerminal: false,
      },
    ],
    loadPreview: async (entityId, ctx) => {
      if (typeof window !== 'undefined') {
        return { title: 'Leave request', subtitle: entityId }
      }
      const { loadLeaveRequestPreview } = await import('./lib/messageObjectPreviews')
      return loadLeaveRequestPreview(entityId, ctx)
    },
  },
]

`loadPreview` Pattern

loadPreview must handle both server and browser environments:

Browser (typeof window !== 'undefined'): return a lightweight placeholder immediately — the compose picker does not need real data at this point.
Server: dynamically import the preview loader function (keeps server-only ORM code out of the client bundle).

Object Type Fields

Field	Required	Description
`module`	yes	Module identifier
`entityType`	yes	Entity type within the module
`messageTypes`	yes	Message types that allow this object
`entityId`	yes	Database entity ID (`module:table`) for the record picker
`optionLabelField`	yes	Field used as the picker option label
`optionSubtitleField`	no	Field used as the picker option subtitle
`labelKey`	yes	i18n key for the object type display name
`icon`	no	Lucide icon name
`PreviewComponent`	yes	React component shown in composer and thread previews
`DetailComponent`	yes	React component shown in message detail objects panel
`actions`	yes	Array of object-level actions (can be empty)
`loadPreview`	yes	Async function returning `{ title, subtitle }` for email/token pages

The compose UI uses:

/api/messages/types
/api/messages/object-types?messageType=<type>
Manual object reference fields (entityModule, entityType, entityId)

to keep object selection deterministic and scoped.

href actions support template placeholders such as {entityId}, {messageId}, and {threadId}.

Component Registry

The typeUiRegistry (packages/core/src/modules/messages/components/utils/typeUiRegistry.ts) is a central lookup table for all custom message UI components, keyed as module:entityType.

Registry Categories

Category	Key format	Purpose
`listItemComponents`	`messages.<type>.listItem`	Custom message list row renderers
`contentComponents`	`messages.<type>.content`	Custom message body renderers
`actionsComponents`	`messages.<type>.actions`	Custom message action renderers
`objectDetailComponents`	`module:entityType`	Business object detail in message detail
`objectPreviewComponents`	`module:entityType`	Business object preview in composer/thread

Components that are not found in the registry fall back to MessageRecordObjectDetail and MessageRecordObjectPreview respectively. The registry is populated at bootstrap time via configureMessageUiComponentRegistry().

Access Control

Module features are declared in packages/core/src/modules/messages/acl.ts:

messages.view
messages.compose
messages.attach
messages.attach_files
messages.email
messages.actions
messages.manage

Default role feature seeding is defined in packages/core/src/modules/messages/setup.ts.

Database Model

Entities are defined in packages/core/src/modules/messages/data/entities.ts:

messages
message_recipients
message_objects
message_access_tokens
message_confirmations

This model supports draft/sent state, recipient status transitions (unread/read/archived/deleted), thread linkage, object attachments, action state, confirmation state, and secure email-link access.

Overview​

End-user flow​

1) List of messages​

2) Compose messages​

3) Attaching objects while composing a message​

4) Message details​

Key Features​

Quick Start​

1. Compose and Send a Message​

2. Save or Update Drafts​

3. Add Real-Time Inbox Badge Updates​

Message Input Schema​

Compose Payload Shape​

Validation Rules​

API Routes​

Conversation-Scoped Operations​

UI Pages​

Backend Pages​

Public Token Page​

Shared UI Components​

Message Types (Module Extension)​

Built-in Types​

Object Types (Deterministic Attachments)​

Widget Component Pattern​

Defining Object Types​

loadPreview Pattern​

Object Type Fields​

Component Registry​

Registry Categories​

Access Control​

Database Model​
